Watson-McDaniel

PRESSURE PILOT PP FOR HD REGULATING VALVES

Pressure pilots PP for HD regulating valves

$964.60

Fast shipping

Across North America

Secure checkout

Your information is safe

Talk to an expert

Get product support

SKU PP Categories Pilots for HD Regulators, Watson Macdaniel Tags Pilots for HD Regulators, Watson McDaniel Brand: Watson-McDaniel

PRESSURE PILOT PP FOR HD REGULATING VALVES The “PP” Pressure Pilot is used with the HD Regulator to control steam pressure in steam mains or for process equipment. Pilot operated regulators will maintain constant downstream pressure even when the inlet pressure to the valve fluctuates or steam usage varies. The PP Pilot can maintain downstream pressure to ± 1 PSIG Model: PP Pilot Body & Cover Material: Ductile Iron or Cast Steel Max Inlet Pressure: 300 PSIG Reduced Outlet Pressure Range: 3-200 PSIG Minimum Inlet Pressure: 15 PSIG (w/ Std Main Valve) 5 PSIG (w/ Low Pressure Main Valve) Accuracy: ± 1 PSIG

Click here for more product details
